Hydraulic control valves / Series DM / DM 70

Hydraulic control valve

SPECIFICATIONS AND TECHNICAL DATA

TYPE
CODE
FLOW RATE
l/min
MAX WORKING PRESSURE
bar
MAX PEAK PRESSURE (P<= 0.1S)
bar
T PORT MAX PRESSURE
bar
MAX PNEUMATIC PRESSURE
bar
DM 70 P DM70P 80 350 500 30 12
DM 70 C DM70C 80 350 500 30 12
DM 70 L DM70L 80 350 500 30 12

TYPE
CODE
FLUID TEMPERATURE
┬░C
VISCOSITY RANGE
cST
FILTERING
ISO 4406 ├čX=75
┬Ám
WEIGHT
kg
MINERAL OIL FLUID
DM 70 P DM70P -25┬░+80┬░C 12-100 20/17 25 3,5 ISO VG 46
DM 70 C DM70C -25┬░+80┬░C 12-100 20/17 25 3,5 ISO VG 46
DM 70 L DM70L -25┬░+80┬░C 12-100 20/17 25 3,5 ISO VG 46
