30MK
 |
 |
Outlet version
Available option
Control option
Model
PTO
11/07/2002
|
| Outlet 1 | |||||
| Torque (NM) | 250 | Replaces | |||
| Int. Ratio | 0,9 | Replaced by | |||
| Teeth number | 27 |
| Electric | Hydraulic | Mechanic | Fixed engagement | Pneumatic | Vacuum system |
| Type | KODE | BESKRIVELSE |
| M | 1 | #Comando Standard |
| M | 2 | #Cmd Meccanico Ant.e Post. |
| M | 3 | #Cmd Meccanico Anteriore |
| P | 1 | #Comando Standard M12x1.25 |
| KODE | BESKRIVELSE | Lubr. Kit | Switch Kit | Reinforced |
| 0 | #Non presente | |||
| 1 | #Tappo ispezione | |||
| 2 | #Con Coper. di Protezione |
;)
TECH.PICTURE
