81V6
81V6
#PTO POS. H. D. VOLVO VT
POSSIBLE SOLUTIONS
81V6
Outlet version
Available option
Control option
Model
PTO
22/06/2016
TEC. SPECIFICATIONS
  Outlet 1
Torque (NM) 1000     Replaces
Int. Ratio 1     Replaced by
Teeth number 12
CONTROL TYPE
 Electric  Hydraulic  Mechanic  Fixed engagement  Pneumatic  Vacuum system
CONTROL VERSIONS (XX)
Type 81Z1 Description
P 1 #Cmd M12x1.5 con raccordo
P 2 #Cmd M12x1.5 senz racc.
AVAILABLE OPTIONS (Y)
81Z1 Description Lubr. Kit Switch Kit Reinforced
0 #Non presente
4 #Con Kit interrut. Kostal
5 #Con Kit interrut. Merit
6 #Con Kit interrut. T.D.S.
81V6
#PTO POS. H. D. VOLVO VT
OUTLET VERSIONS (ZZZ)
81Z1 Description
204 Pump drive SE 4-Bolts
   Conversion kit
Pneumatic/Mechanic
Mechanic/Pneumatic
Electric control
#UNI da DIN 5462 (SE)
  Flange kit
81Z1 Description
 DIN 00 x PTO 0081
 DIN 10 x PTO 0081
 SP 1120 x PTO 0081
 SP 1300 x PTO 0081
 KIOKUTO "B"x 0081
 SP 1400 x PTO 0081
  Switch kit
81Z1 Description
 #DIN2.5 M16x1.5 N.C.
 #TDS M 16x1.5 N.C.
 #EATON N.C.
   TECH.PICTURE
81V6
